LC-AMF0810
8 Chanel’s multi function Actuator
The LC-AMF0810 is a 8-channel DIN-rail-mounted multifunctional actuator for independent switching of loads by means of closing contacts. The 230 V ac switching output can be controlled by the push buttons on the front.
A green LED indicates the status of the channel.
It features 10 A bitable relays with contacts connected directly to the terminals, without phase sharing.
The screw terminals can accept cable sections up to 5 mm2. The relays used can withstand an inrush current of up to 120 A in the first 10 MS, making them particularly suitable for controlling inductive loads such as fluorescent or neon lamps.
Data Sheet
- Input voltage: 230 V ac, 50/60 Hz
- Power supply: KNX bus, 29 V dc SELV
- Consumption on bus: 12 mA
- Rated current IN: 10 A
- Operating Temperature: -5 ÷ +45 °C (internal use)
- Connection to the BUS: coupling terminal, 2 pins, d=0,8 mm
- Electric connections: screw terminals, max. cable section 5 mm2 (AWG10)
- Degree of protection: IP 20
- Dimensions: 8 DIN modules
KNX functions
- Switching function
- Staircase light function
- Scenario function
- Logical functions: 16 generic logical operators are available to be assigned to the desired channels without restrictions
- Channel status feedback
- Fan control: support up to three level fan speed
- Checking roller shutters and venetian blinds (AC/DC)
- Thermostatic valve control with PWM algorithm and fan coil devices.
- Support 2 valve control types: 3point,open and close, continuous ,PWM and 2state-ON/OFF, and support disable/enable HEAT and COOL, valve status response, valve purge etc..
